1.5SMC440A
Surface Mount – 1500W > 1.5SMC series ESD 抑制器/TVS 二极管 1.5SMC440A
The 1.5SMC series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events.
• 1500W peak pulse power
capability at 10/1000μs
waveform, repetition rate
(duty cycles):0.01%
• Excellent clamping
capability
• Low incremental surge
resistance
• Typical IR less than 1μA
when VBR min>12V
• For surface mounted
applications to optimize
board space
• Low profile package
• Built-in strain relief
• Typical failure mode is
short from over-specified
voltage or current
• Whisker test is conducted
based on JEDEC
JESD201A per its table 4a
and 4c
• IEC-61000-4-2 ESD
30kV(Air), 30kV (Contact)
• ESD protection of data
lines in accordance with
IEC 61000-4-2
• EFT protection of data
lines in accordance with
IEC 61000-4-4
• Fast response time:
typically less than 1.0ps
from 0V to BV min
• Glass passivated chip
junction
• High temperature
to reflow soldering
guaranteed: 260°C/40sec
• VBR @ TJ
= VBR@25°C
x (1+αT x (TJ
- 25))
(αT:Temperature
Coefficient, typical value
is 0.1%)
• Plastic package is
flammability rated V-0 per
Underwriters Laboratories
• Meet MSL level1, per
J-STD-020, LF maximun
peak of 260°C
• Matte tin lead–free plated
• Halogen free and RoHS
compliant
• Pb-free E3 means 2nd
level interconnect is
Pb-free and the terminal
finish material is tin(Sn)
(IPC/JEDEC J-STD-
609A.01)
1.5SMC440A Applications
TVS devices are ideal for the protection of I/O Interfaces,
VCC bus and other vulnerable circuits used in Telecom,
Computer, Industrial and Consumer electronic
applications.
型号:1.5SMC440A
制造商:Littelfuse
产品种类:ESD 抑制器/TVS 二极管
RoHS: 详细信息
系列:1.5SMC
极性:Unidirectional
通道数量:1 Channel
端接类型:SMD/SMT
击穿电压:462 V
工作电压:376 V
钳位电压:602 V
Ipp - 峰值脉冲电流:2.5 A
封装 / 箱体:DO-214AB-2
Pd-功率耗散:1.5 kW
工作温度:- 65 ℃
工作温度:+ 150 ℃
封装:Cut Tape
封装:Reel
商标:Littelfuse
产品类型:TVS Diodes / ESD Suppression Diodes
工厂包装数量:3000
子类别:TVS Diodes / ESD Suppression Diodes
单位重量:210 mg
