LM317T-DG

线性稳压器 Dual Guage ADJ 1.2V to 37V 1.5A

Description LM317T-DG

The LM217, LM317 are monolithic integrated circuits in TO-220, TO-220FP and

D2PAK packages intended for use as positive adjustable voltage regulators.

They are designed to supply more than 1.5 A of load current with an output voltage

adjustable over a 1.2 to 37 V range.

The nominal output voltage is selected by means of a resistive divider, making the

device exceptionally easy to use and eliminating the stocking of many fixed

regulators.

Features LM317T-DG

• Output voltage range: 1.2 to 37 V

• Output current in excess of 1.5 A

• 0.1% line and load regulation

• Floating operation for high voltages

• Complete series of protections: current limiting, thermal shutdown and SOA control

型号: LM317T-DG

产品种类: 线性稳压器

RoHS:  无铅环保

安装风格: Through Hole

封装 / 箱体: TO-220

输出端数量: 1 Output

极性: Positive

输出电压: 1.2 V to 37 V

输出电流: 1.5 A

输出类型: Adjustable

输入电压: 40 V

输入电压: 4.2 V

工作温度: 0 C

工作温度: + 125 C

负载调节: 0.5 %

线路调整率: 0.04 %/V

系列: LM317

封装: Tube

商标: STMicroelectronics

PSRR/纹波抑制—典型值: 80 dB

产品类型: Linear Voltage Regulators

工厂包装数量: 50

子类别: PMIC - Power Management ICs

单位重量: 2.300 g
